VFA15ADTH2 – Wall-mount Type Ventilation Fan
DELTA VFA15ADTH2 wall mount fan feature quiet operation, low power consumption, and Delta’s durable brushless DC motor.
- Mounting opening ：160 mm
- VFA15ADTH2: High Single Speed (CMH 200)
- 5 – Years Warranty
Description
| Model | Grille Size | Mounting Opening | Install Glss Thickness | Weight | Power Rating | Power Consumption | Maximum Air Flow | Maximum Air Pressure | Noise | Remark | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | mm | mm | mm | kg | VAC/Hz | WAlts | CMH | CFM | Pa | inAq | dB-A | |
| VFA15ADTH2 | 200 x 200 | Ø160 | 3-25 | 0.7 | 220/50 | 4 | 200 | 118 | 50 | 0.2 | 38 | |
- The max. air flow is measured in free air; max air pressure is measured at zero air flow.
- Noise is measured in semi-anechoic chamber in free air, one meter from intake, right and left side. 3 microphones to average.
- All readings are typical values at rated voltage.
- Specifications are subject to change without notice.
