VFA10AXTH – Wall-mount Type Ventilation Fan
DELTA VFA10AXTH wall mount fan feature quiet operation, low power consumption, and Delta’s durable brushless DC motor.
- Mounting opening ：100 mm
- VFA10AXTH: Dual Speed (CMH 60/95)
- 5 – Years Warranty
Description
| MODEL | GRILLE SIZE | MOUNTING OPENING | DUCT SIZE | WEIGHT | POWER RATING | POWER CONSUMPTION | MAXIMUM AIR FLOW | MAXIMUM AIR PRESSURE | NOISE | REMARK | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PART NO. | mm | mm | mm | kg | VAC/Hz | WAlts | CMH | CFM | Pa | inAq | dB-A | |
|
VFA10AXTH
|
158 x 158
|
210 x 210
|
Ø100
|
0.33
|
220/50
|
1.9 | 60 | 35 | 20 | 0.08 | 30 | Low Speed |
| 4.7 | 95 | 56 | 50 | 0.2 | 46 | Full Speed | ||||||
- The max air flow is measured in free air; max air pressure is measured at zero air flow.
- Noise is measured in semi-anechoic chamber in free air, one meter from intake, right and left side. 3 microphones to average.
- All readings are typical values at rated voltage.
- VFA10AXTH operates in low speed mode (green LED) or high speed mode (amber LED) by cycling ON/OFF switch. Default is high speed.
- Specifications are subject to change without notice.
