Axial extract high-performance fans, compatible with the Design decorative panels
  • Impeller type: Axial
Categories: ,
Add to quote
Description
Model range
Downloads
  • Can be mounted with decorative panels by Design Concept systems.
  • The fan’s impeller and casing are made of durable high-quality UV-resistant plastic. The fan doesn't yellow and retains its original appearance.
  • The reliable motor is rated for continuous operation and is equipped with overheating protection.
  • The special impeller design allows to increase the fan's performance and does not require additional maintenance.

ABOUT DESIGN CONCEPT SYSTEM

Design Concept system is a design solution for ventilation that consists of the base (fan, grille or diffuser) and a range of stylish panels with a variety of materials, colors and textures to match the base. Now ventilation is not just efficient but also matches the room’s design very well.

FAN'S ADVANTAGES

High performance

  • High air flow ensures fast removal of excessive humidity and unpleasant smell from the room.

Reliability

  • The motor is equipped with overheating protection and is maintenance-free for the whole motor service life. The fan’s impeller and casing are made of durable high-quality UV-resistant plastic.

Multipurpose use

  • The fan is rated for both continuous and interval operation. The fan can be mounted on walls, in air ducts or air pits.

Use

  • Residential premises
  • Offices
  • Utility spaces with normal and increased humidity

MODIFICATIONS

Models of this series can be equipped with extra options:

Base L

  • The fan is equipped with a motor on ball bearings. The bearings are maintenance-free and are filled with grease for the whole motor service life. This motor allows to mount the fan at any angle.

Base turbo

  • The fan is equipped with a motor of increased power, enhancing its performance.

Base B

  • The fan is equipped with a pull cord switch to be turned on and off manually.

Base T

  • The fan is equipped with an adjustable turn-off delay timer. The timer allows to prolong the fan’s operation for 2 to 30 minutes after it is switched off. This allows to reduce humidity and remove unpleasant smell.

Base TH

  • The fan is equipped with an adjustable turn-off delay timer and a humidity sensor. The integrated humidity sensor controls the fan’s operation based on the indoor humidity level. If the set humidity level is exceeded, the fan is autonomously triggered and operates until the humidity level is normal. When the normal humidity level is reached, the fan keeps working for until the timer countdown is up and turns off.
Lineup Vents Base Maximum airflow, m³/h Sound pressure level LpA at 3 m, dB(A) Humidity sensor Timer
Vents 100 Base 100 34 ✖ ✖
Vents 100 Base K 100 34 ✖ ✖
Vents 100 Base K L 100 34 ✖ ✖
Vents 100 Base T K 100 34 ✖ Turn off timer
Vents 100 Base TH 100 34 ✔ Turn off timer
Vents 100 Base TH K 100 34 ✔ Turn off timer
Vents 100 Base Q 82 26 ✖ ✖
Vents 100 Base L Q 82 26 ✖ ✖
Vents 100 Base T L Q 82 26 ✖ Turn off timer
Vents 100 Base TH L Q 82 26 ✔ Turn off timer
Vents 100 Base turbo 122 36 ✖ ✖
Vents 100 Base L turbo 122 36 ✖ ✖
Vents 125 Base 180 35 ✖ ✖
Vents 125 Base K L 180 35 ✖ ✖
Vents 125 Base Q 147 29 ✖ ✖
Vents 125 Base L Q 147 29 ✖ ✖
Vents 125 Base T K L Q 147 29 ✖ Turn off timer
Vents 125 Base T L Q 147 29 ✖ Turn off timer
Vents 125 Base TH L Q 147 29 ✔ Turn off timer
Vents 125 Base turbo 217 37 ✖ ✖
Vents 150 Base 280 34 ✖ ✖
Vents 150 Base (220 V/60 Hz) ✖ ✖
