Duct fan TYPHOON

Description

Mixed type duct axial fan in a plastic housing. Designed for supply and exhaust ventilation systems of industrial, public and residential buildings. It has a dismountable design, which simplifies maintenance: a removable central block with a motor, impeller and terminal box is attached to the side pipes with plastic clamps. TYPHOON 100 2SP is equipped with a two-speed single-phase ball bearing motor with long service life, built-in thermal protection and automatic restart. The asymmetrical shape of the terminal box makes it easy to connect the power cable. The fan has two operating speeds; the speed is selected when connecting power to the terminals, or using a button (included in the kit, installed independently at the request of the user). The device is suitable for horizontal and vertical installation; fastening to the surface is carried out using self-tapping screws.
