Duct fan CYCLONE

Description

Commercial duct centrifugal fan, made of high-strength plastic. Thanks to the material it is made of, it is highly resistant to corrosion and is well suited for rooms with high humidity. Designed for installation at any point in the supply and exhaust ventilation system and at any angle. The fan is equipped with a single-phase motor with an external rotor equipped with an impeller with backward-curved blades. The motor has thermal protection with automatic restart. Connection to the network is carried out in a sealed terminal box, the degree of protection of the electrical equipment shell from the penetration of solid particles and water is IPX4, the motor is IP44. The box with the fan contains a bracket for surface mounting and two screws for attaching the bracket to the case.
